P3.91 Ultra Thin Indoor Rental LED Display
P3.91 Ultra Thin Indoor Rental LED Display is a type of indoor LED used for different purposes and locations, such as shopping malls, theaters, advertising walls, and other purposes.
- Product Features
- Parameters
- Related Videos
- Easy Assembly
P3.9 Ultra Thin Indoor Rental LED Display has a modular design, easy assembly, and maintenance.
- Module Size
240*240mm, smooth surface, module gap small, high precision
- Lightweight
P3.9 Ultra Thin Indoor Rental LED Display Cabinet size: 480mm x 480mm x 80mm, weight: 8.5kg/pc.
- Thin
Die-cast aluminum design, high precision, thickness only 80mm.
- Fast Installation
Fast locks, Easy to assemble and disassemble.
- Low Power Consumption
Excellent cooling design, no fans or air-conditioners needed, noiseless, low power consumption, and cost-effective.
| LED MODULE PARAMETER | |
| Pixel pitch (mm) | 3.91 |
| Pixel configuration | 3 in 1 |
| Encapsulation | SMD2121 |
| Colors matches | 6:3:1 |
| Module resolution (pixels) | 64 x 64 |
| Module pixel | 4096 |
| Module size (mm) | 250 x 250 |
| LED CABINET SPECIFICATION | |
| Cabinet size (mm) | 500 x 500 x 100 |
| Cabinet resolution (pixels) | 128 x 128 |
| Cabinet pixels (pixels) | 16384 |
| Cabinet material | Extrusion Aluminum |
| Cabinet weight (kg) | 8kg |
| LED DISPLAY SPECIFICATION | |
| Pixel density(pixel/m2) | 65536 |
| Brightness(cd/m2) | ≥1500 (adjustable) |
| Brightness adjusted | 100 grade by software or by Auto-optic induced |
| View angle | Horizontal 140°; Vertical 140° |
| Best viewing distance (m) | ≥3.5m |
| Communication distance(m) | <100meter by Internet Cable(without Relay; Multimode fiber cable ＜ 500m; Single-mode fiber cable ＜ 20km |
| Display work method | 1/16 Scan |
| LED driving method | Constant driving current |
| Color contrast ratio | 4000:1 |
| Gray Grade | 16bit |
| Display Color | 439, 804, 651, 110 |
| Refresh Frequency (Hz) | ≥1000 |
| Picture display method | Intellective control technology, test-itself technology, correct technology, Synchronization Control |
| Input signal | DVI (S-VIDEO, CVBS, DP, HDMI, VGA, PAL/NTSC, etc. through a Video processor converting ) |
| System operating | WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc. |
| Front/Rear IP Level | IP43 |
| Working temperature(ºC) | -20～+60 |
| Stored temperature (ºC) | -30～+80 |
| Operation humidity(RH) | 0-95% |
| Display Lifetime(hours) | Ten years or more( natural environment) 100000 hours( ideal environment) |
| Maintenance | Rear side |
| Working Voltage | AC110 / AC220V±10% 47～63HZ |
| Out of controlled dot | ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wavelength are both >10% depart to the normal one) |
(P3.91 Indoor Rental LED Display Screen)
