P10 Outdoor Stadium LED Screen


P10 outdoor stadium LED screen has all-aluminum material, lighter, thinner, more worry-free; ultra-high contrast corrugated light absorbing mask.

It has all-aluminum material, lighter, thinner, more worry-free.




  • It has all-aluminum material, lighter, thinner, more worry-free.
  • Has high contrast corrugated light absorbing mask.
  • Ultra-high contrast.
  • The body of the precision aluminum alloy box; leveling accuracy is ≤0.015mm.
  • Aluminum box body, less weight, reduce transportation costs and installation labor costs.
  • Rigid connection design, support hot plug maintenance.
  • Support intelligent spot check, monitor the whole screen.
  • It has zero seam stitching, natural flat.
  • Complete pre – and post-maintenance support for different environments.
  • The case can reach IP65 waterproof grade before and after. Stainless steel quick lock + precision aluminum box, quickly assembled, and good flatness.
  • Single point brightness and color correction are performed before delivery to ensure the consistency of brightness and color.
  • A standard intelligent module can store calibration data.
Pixel Pitch (mm)

10

Pixel Configuration

SMD2727

Panel Resolution

40 x 30

Panel Dimension

400 x 300mm

Pixel Density

10000

Panel Weight

22.4kg

Brightness

6500

Chromaticity Uniformity

≥99%

Cabinet Flatness

<=0.01

Module

2X3

Resolution

80X90

Display Work Method

1/6scan

Contrast

5000:1

Grey Scale

65536

Refresh Rate

3840

IP Rating

IP65

Operating Temp./Humidity Range (℃/RH)

-20~60℃ / 10%~85%

Storage Temp./ Humidity Range (℃/RH)

-20~60℃ / 10%~85%

Perspective

160°/ 160°

Color Temperature (K)

3200-9300





(Sports Stadium LED Display)
