P3.75 LED Module
The P3.75 LED Screen Panel is ideal for rental screen displays and single-color screens. A single-color or dual-color LED screens are used as mini-advertising screens or signs for small establishments with minimal space for huge LED boards. It comes in a lightweight design can come with crashproof edges, front maintenance, and more.
Also, the P3.75 LED Module makes various sizes and applications and is conveniently affordable. If you’re a start-up business owner but would like to use lights and screen designs to engage your customers, this product might be ideal.
YUCHIP also provides guides, manuals, and step-by-step assistance for the proper operation of the device, installation, warranty, and other services. Please message us to know more.
- Parameters
- Features & Descriptions
- Related Videos
|
P3.75 LED Module Specification |
||||||
| Pixel Pitch (mm) |
3.75 |
|||||
| Pixel Configuration |
SMD3528 |
|||||
| Encapsulation |
3 in 1 |
|||||
| Colors Matches |
6:3:1 |
|||||
| Module Resolution (WxH) |
64 x 64 |
|||||
| Module Size (mm) |
250 x 250 |
|||||
|
P3.75 LED Display Specification |
||||||
| Pixel Density（pixel/m²） |
71111 |
|||||
| Brightness（cd/m²） |
2000 (Optional) |
|||||
| Brightness Adjusted |
100 grade by software or by Auto-optic induced |
|||||
| View Angle |
Horizontal 140°; Vertical 140° |
|||||
| Best Viewing Distance (m) |
≥ 3m |
|||||
| Communication Distance（m） |
<100meter by Internet Cable（without Relay; Multimode fiber cable ＜ 500m; Single-mode fiber cable ＜ 20km |
|||||
| Display Work Method |
1/16 Scan |
|||||
| LED Driving Method |
Constant driving current |
|||||
| Color Contrast Ratio |
1800:1 |
|||||
| Gray Grade |
16bit |
|||||
| Display Color |
439, 804, 651, 110 |
|||||
| Refresh Frequency (Hz) |
≥1920, ≥3840 Optional |
|||||
| Picture Display Method |
Intellective control technology, test-itself technology, correct technology, Synchronization Control |
|||||
| Input Signal |
DVI (S-VIDEO, CVBS, DP, HDMI, VGA, PAL/NTSC, etc. through Video processor converting) |
|||||
| System Operating |
WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc. |
|||||
| Control System | ||||||
| Front/Rear IP Level |
IP43 |
|||||
| Working Temperature (ºc) |
-20～+40 |
|||||
| Stored Temperature (ºc) |
-40～+80 |
|||||
| Operation Humidity (RH) |
0-95% |
|||||
| Display Lifetime (hours) |
Ten years or more (natural environment) 100000 hours (ideal environment) |
|||||
| Maintenance |
Rear / Front Side |
|||||
| Working Voltage |
AC110 / AC220V±10% 47～63HZ |
|||||
| Power Consumption |
Max: 700W/㎡ ; Ave:250W/㎡ |
|||||
| Out Of Controlled Dot |
≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wavelength are both >10% depart from the normal one) |
|||||
FEATURES
The P3.75 LED Screen Panel has the following features:
- Single/ Dual Color
The P3.75 LED Display Panel is available for small and single-color designs. If you’re a start-up business owner, this is a friendly device. You may use a signboard to quickly capture your customers and tell them what products or services you offer.
- Lightweight
Each module/panel weighs lesser than typical LED screens. It eases mobility, installation, and dismantling. Also, the lightweight product saves costs for labor during certain operations as it may require a smaller and lesser workforce.
- Rental Design
The P3.75 LED Display Panel comes with individual boxes designed for rental events. With packages, the product is safe for transport from time to time.
- Dual Maintenance
You can choose which side to perform maintenance with. Whichever side works for you; convenient, more manageable, dual care, and cost-effective.
- Energy-saving
We designed the P3.75 LED Screen Panel adaptive to the changes in consumption. There is no need to worry about high electricity bills with a lesser energy requirement.
CATEGORY
The P3.75 LED Module is included in the following product series. YUCHIP also welcomes customization for a different application or use. We have a professional R&D team who’s ready to serve and help you make the blueprint of your desired project outcomes.
- Indoor Fixed LED Display
- Trade Show LED Display
- Flexible LED Screen
- LED Theater Screen
- Museum LED Screen
- Indoor Rental LED Display
- Commercial LED Display
- Transportation LED Screen
- LED School Sign
- Hospitality LED Screen
- Control Room Display Screen
- DJ LED Wall
Please message us for more information and inquiries.
