P3 Indoor Fixed LED Display


P3 Indoor Fixed LED Display is of high resolution for Indoor rental events that require a high-quality presentation, and its cost is lower for large-sized indoor LED screen use.




  • Low Brightness and High Grayscale

P3 indoor SMD led screen is endowed with superior consistency under low brightness status, even reduced to 20% brightness.

  • Thin and Light Panel Design

85mm panel depth and 16kg panel weight lead to significant transportation and installation savings than traditional panels.

  • High Refresh Rate

P3 Indoor Fixed LED Display has an SMD system resulting in a more precise and high resolution. It has a high refresh rate that is ideal for indoor fixed LED displays.

  • Easy Maintenance Features

The indoor fixed display comes with easy maintenance features, which are through the front side. You can use a magnet to detach the module from the cabinet. From there, you can check the inside parts if there’s a problem or needs cleaning.

LED MODULE PARAMETER

Pixel pitch (mm)

3

Pixel configuration

1R1G1B

Encapsulation

SMD2121

Colors matches

6:3:1

Module resolution (pixels)

80*80

Module pixel

6400

Module size (mm)

240*240*15mm

LED CABINET SPECIFICATION

Cabinet size (mm)

480*480*80mm

Cabinet resolution (pixels)

160*160

Cabinet pixels (pixels)

25600

Cabinet material

Cast aluminum

Cabinet weight (kg)

8.5kg

LED Display Specification

Pixel density(pixel/㎡)

111111

Brightness (cd/㎡)

800-1200 CD/㎡ (adjustable)

Brightness adjusted

100 grade by software or by Auto-optic induced

View angle

Horizontal 160°; Vertical 160°

Best viewing distance (m)

≥3m

Communication distance (m)

<100meter by Internet Cable(without Relay; Multimode fiber cable < 500m; Single-mode fiber cable < 20km

Display work method

1/16 Scan

LED driving method

Constant driving current

Color contrast ratio

4000:1

Gray Grade

16bit

Display Color

439, 804, 651, 110

Refresh Frequency (Hz)

1000-2400Hz

Picture display method

Intellective control technology, test-itself technology, correct technology, Synchronization Control

Input signal

DVI (S-VIDEO, CVBS, DP, HDMI, VGA, PAL/NTSC, etc. through a video processor converting)

System operating

WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc.

Front/Rear IP Level

IP30

Working temperature (ºC)

-20~+70

Stored temperature (ºC)

-30~+80

Operation humidity (RH)

0-95%

Display Lifetime (hours)

10 years or more (natural environment) 100000 hours (ideal environment)

Maintenance

Front

Working Voltage

AC110 / AC220V±10% 47~63HZ

Out of controlled dot

≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wavelength are both >10% depart to the normal one)



(P3 Indoor HD LED Display Screen)
