P5 LED Screen


The P5 LED screen is an outdoor rental LED display ideal as a stage background in various rental events. P5 Outdoor Rental LED Display has advanced cabinet design, seamless, ensuring the entire screen’s flatness.

It comes with three years or five years warranty, easy to install and maintain. In addition, outdoor rental LED display products are certified by CE, Rohs, FCC, etc.

P5 LED wall price is usually higher than conventional screens because it has both fixed and rental properties and outdoor and semi-outdoor installation. It has a small pixel pitch which means its components are nearly expensive than other outdoor rental LED displays.




P5 LED screen as an outdoor rental LED display is an ideal solution for stage design and background needs. With its great structural design, the P5 LED wall price might be a lot higher than other outdoor rental LED displays. Below are it’s few key points.

Key Points

  • You can choose from a 500mm x 500mm or 500mm x 1000mm box cabinet size that utilizes a die-cast aluminum design. Both characteristics are thin and light; the 500mm x 500mm cabinet weighs only 7.5 kg.
  • P5 LED screen has high brightness and high contrast, making the screen have no delay and smear phenomenon under direct sunlight.
  • P5 LED screen has a clear picture without flicker and distortion.
  • Outdoor Rental LED Display, such as the P5 LED screen, has advanced cabinet design, seamless, ensuring the entire screen’s flatness.
  • It comes with three years warranty, easy to install & maintain. Besides, outdoor rental LED display products are certified by CE, Rohs, FCC, etc., so you can be sure of excellent quality and legal processes.

Why Do You Need An Outdoor Rental LED Display?

An outdoor rental LED display plays a vital role in various outdoor events. Events such as concerts, flashmobs, outdoor theatrical performances, musicals, etc., become more promising and engaging when installing an LED screen as the stage background.

The music, lighting, and stage design are given a justifiable overall look when LED screens such as outdoor rental LED displays are present.

The outdoor rental LED display, such as the P5 LED screen, may vary in price and costs. It may include installation costs, changes in manufacturing equipment if you opt to customize (higher or lower add-ons). Above all, the P5 LED Wall price may be high, making it a considerable investment, but its consequences are also valuable.

In addition, if you need an interactive dance floor, YUCHIP also provides an outdoor rental LED display which you can also use as a rental dance floor

P5 Outdoor Rental LED Display Module Specification

Pixel Pitch (mm)

5.95

Pixel Configuration

SMD3535

Encapsulation

3 in 1

Colors Matches

6:3:1

Module Resolution (pixels)

84 x 168

Module Pixel (pixels)

2048

Module Size (mm)

320 x 160

P5 Outdoor Rental LED Display Cabinet Specification

Cabinet Size (mm)

500 x 1000 and customized

Cabinet Resolution (pixels)

192 x 192

Cabinet Pixels (pixels)

36864

Cabinet Material

Steel / Aluminum / Die casting aluminum

Cabinet Weight (kg)

12.5

P5 Outdoor Rental LED Display Screen Specification

Pixel Density (pixel/m²)

28224

Brightness (cd/m²)

≥5000 (adjustable)

Brightness Adjusted

256 grade by software or by Auto-optic induced

View Angle

Horizontal 140°; Vertical 140°

Best Viewing Distance (m)

≥6m

Communication Distance (m)

<100meter by Internet Cable (without Relay; Multimode fiber cable < 500m; Single-mode fiber cable < 20km

Display Work Method

1/7 Scan

LED Driving Method

Constant driving current

Color Contrast Ratio

3000:1

Gray Grade

16bit

Display Color

439, 804, 651, 110

Refresh Frequency (Hz)

≥2400 Optional

Picture Display Method

Intellective control technology, test-itself technology, correct technology, Synchronization Control

Input Signal

DVI (S-VIDEO, CVBS, DP, Multimode, HDMI, VGA, PAL/NTSC, etc. through Video processor converting )

System Operating

WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc.

Control System

Novastar, Linsn, LEDvision, LEDset

Front/Rear IP Level

IP65

Working Temperature (ºc)

-20~+40

Stored Temperature (ºc)

-40~+80

Operation Humidity (RH)

0-95%

Display Lifetime(Hours)

Ten years or more (natural environment)

100000 hours (ideal environment)

Maintenance

Rear / Front side

Working Voltage

AC110 / AC220V±10% 47~63 Hz

Power Consumption

Max: 700W/㎡ ; Ave:250W/㎡

Out Of Controlled Dot

≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wavelength are both >10% depart to the normal one)



(P5.95 Outdoor Rental LED Display)
