- Customers can choose 500mm * 500mm or 500mm*1000mm box cabinet, die-cast aluminum design. The characteristics of both are thin and light; the 500mm * 500mm cabinet is only 7.5kg.
- P6.25 LED Display has high brightness and high contrast, making the screen without delay and smear phenomenon under direct sunlight.
- It has a clear picture without flicker and distortion.
- P6.25 Outdoor Rental LED Display has advanced cabinet design, seamless, ensuring the entire screen’s flatness.
- It comes with three years warranty, easy to install & maintain. Products are certified by CE, Rohs, FCC, etc.
P6.25 Outdoor Rental LED Display
YuChip P6 Outdoor LED screen has advanced cabinet design, seamless connection, ensuring the entire screen’s high flatness and perfect visual effect.
It comes with three years warranty, easy to install & maintain. Products are certified by CE, Rohs, FCC, etc.
- P6 Outdoor LED Screen Product Features
- P6 Outdoor LED Screen Parameters
LED MODULE PARAMETER | |
| Pixel pitch (mm) | 6.25 |
| Pixel configuration | 3 in 1 |
| Encapsulation | SMD3528 |
| Colors matches | 6:3:1 |
| Module resolution (pixels) | 40 x 40 |
| Module pixel | 1600 |
| Module size (mm) | 250 x 250 |
LED CABINET SPECIFICATION | |
| Cabinet size (mm) | 500 x 500 x 90 |
| Cabinet resolution (pixels) | 80 x 80 |
| Cabinet pixels (pixels) | 6400 |
| Cabinet material | Aluminum |
| Cabinet weight (kg) | 8kg |
LED DISPLAY SPECIFICATION | |
| Pixel density (pixel/㎡) | 25600 |
| Brightness (cd/㎡) | ≥1500 (adjustable) |
| Brightness adjusted | 100 grade by software or by auto-optic induced |
| View angle | Horizontal 140°; Vertical 140° |
| Best viewing distance (m) | ≥6m |
| Communication distance (m) | <100meter by Internet Cable(without Relay; Multimode fiber cable ＜ 500m; Single-mode fiber cable ＜ 20km |
| Display work method | 1/8 Scan |
| LED driving method | Constant driving current |
| Color contrast ratio | 1800:1 |
| Gray Grade | 16bit |
| Display Color | 439, 804, 651, 110 |
| Refresh Frequency (Hz) | ≥1000 |
| Picture display method | Intellective control technology, test-itself technology, correct technology, Synchronization Control |
| Input signal | DVI (S-VIDEO, CVBS, DP, HDMI, VGA, PAL/NTSC, etc. through a video processor converting) |
| System operating | WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc. |
| Front/Rear IP Level | IP43 |
| Working temperature (ºC) | -20～+60 |
| Stored temperature (ºC) | -30～+80 |
| Operation humidity (RH) | 0-95% |
| Display Lifetime (hours) | 10 years or more (natural environment) 100000 hours (ideal environment) |
| Maintenance | Rear side |
| Working Voltage | AC110 / AC220V±10% 47～63Hz |
| Out of controlled dot | ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wavelength are both >10% depart to the normal one) |
