P8 Indoor Fixed LED Display
P8 Indoor Fixed LED Display is one of YUCHIP’s most famous indoor products.
The cabinet measures 960 x 960 x 150 mm; also, we can customize the size according to your preference.
- Product Features
- Parameters
- Related Videos
- P8 Indoor Fixed LED Display is one of YUCHIP’s most famous indoor products.
- IF8 utilizes SMD3528 as pixel configuration.
- The cabinet measures 960 x 960 x 150 mm; also, we can customize the size according to your preference.
- The raw material is made out of steel, ensuring a more vigorous and stable installation with long-life span features.
- The brightness can reach up to 7000 cd/㎡ and be adjusted up or down depending on circumstances.
- The ideal life span in a natural environment is ten years or more; thus, it’s cost-effective and highly reliable.
- IF8 has various installation options such as wall-mounted, building-mounted, hanging, etc.
- It has a clear and vivid resolution that is perfect for closer viewing, especially for indoor conferences, restaurants, meetings, and other indoor events.
| LED Module Parameter | |
| Pixel Pitch (mm) | 8 |
| Pixel Configuration | SMD3528 |
| Encapsulation | 3 in 1 |
| Colors Matches | 6:3:1 |
| Module Resolution (pixels) | 40 x 40 |
| Module Pixel | 1600 |
| Module Size (mm) | 320 x 320 |
| LED Cabinet Specification | |
| Cabinet Size (mm) | 960 x 960 x 150 |
| Cabinet Resolution (pixels) | 120 x 120 |
| Cabinet Pixels (pixels) | 14400 |
| Cabinet Material | Steel |
| Cabinet Weight (kg) | 55 |
| LED Display Specification | |
| Pixel Density (pixel/㎡) | 15625 |
| Brightness (cd/㎡) | ≥7000 (adjustable) |
| Brightness Adjusted | 100 grade by software or by Auto-optic induced |
| View Angle | Horizontal 160°; Vertical 160° |
| Best Viewing Distance (m) | ≥6m |
| Communication Distance (m) | <100meter by Internet Cable(without Relay; Multimode fiber cable ＜ 500m; Single-mode fiber cable ＜ 20km |
| Display Work Method | 1/4 Scan |
| LED Driving Method | Constant driving current |
| Color Contrast Ratio | 1800:1 |
| Gray Grade | 16bit |
| Display Color | 439, 804, 651, 110 |
| Refresh Frequency (Hz) | ≥600 |
| Picture Display Method | Intellective control technology, test-itself technology, correct technology, Synchronization Control |
| Input Signal | DVI (S-VIDEO, CVBS, DP, HDMI, VGA, PAL/NTSC, etc. through Video processor converting ) |
| System Operating | WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc. |
| Front/Rear IP Level | IP65 |
| Working Temperature (ºC) | -20～+60 |
| Stored Temperature (ºC) | -30～+80 |
| Operation Humidity (RH) | 0-95% |
| Display Lifetime (hours) | 10 years or more (natural environment) 100000 hours (ideal environment) |
| Maintenance | Front & Rear |
| Working Voltage | AC110 / AC220V±10% 47～63HZ |
| Out of Controlled Dot | ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one) |
