P6 Indoor LED Display
P6 Indoor LED Display has a vivid and clear resolution. P6 has a wide viewing angle of 140 degrees and excellent brightness of up to 1200 nits; it will surely bring you an unprecedented visual experience in an indoor environment.
Plus, P6 LED screen is cost-effective for you to build large size video displays.
- P6 Indoor LED Display Product Features
- Parameters
- Related Videos
- P6 Indoor HR LED Display has a vivid and clear resolution. With a brightness of up to 2000 nits, it will surely bring you an unprecedented view in an indoor environment.
- This P6 indoor high-resolution has a high refresh rate and high grayscale with millions of colors for indoor fixed installation.
- YUCHIP P6 Indoor Displays and all of our LED products undergo a series of aging tests to ensure reliability, good standing, and performance.
- P6 Indoor HR LED Display cabinet measures 960 x 960, and we can also customize it according to your preference.
- Its maintenance may vary; if for fixed installation, the maintenance is through the front; however, the maintenance can be from the rear side when it has temporary or hanging installation.
- P6 indoor LED display is widely used in various indoor locations such as theaters, schools, government offices, hotels and restaurants, museums, etc.
LED MODULE PARAMETER | ||||||||
Pixel pitch (mm) | 6 | |||||||
Pixel configuration | 3 in 1 | |||||||
Encapsulation | SMD3528 | |||||||
Colors matches | 6:3:1 | |||||||
Module resolution (pixels) | 40 x 40 | |||||||
Module pixel | 1600 | |||||||
Module size (mm) | 240 x 240 | |||||||
LED CABINET SPECIFICATION | ||||||||
Cabinet size (mm) | 960 x 960 | |||||||
Cabinet resolution (pixels) | 80 x 80 | |||||||
Cabinet pixels (pixels) | 6400 | |||||||
Cabinet material | Aluminum | |||||||
Cabinet weight (kg) | 19kg | |||||||
LED DISPLAY SPECIFICATION | ||||||||
Pixel density(pixel/㎡) | 27777 | |||||||
Brightness(cd/㎡) | ≥2000 (adjustable) | |||||||
Brightness adjusted | 100 grade by software or by Auto-optic induced | |||||||
View angle | Horizontal 140°; Vertical 140° | |||||||
Best viewing distance (m) | ≥5m | |||||||
Communication distance(m) | <100meter by Internet Cable(without Relay; Multimode fiber cable < 500m; Single-mode fiber cable < 20km | |||||||
Display work method | 1/10 Scan | |||||||
LED driving method | Constant driving current | |||||||
Color contrast ratio | 1800:1 | |||||||
Gray Grade | 16bit | |||||||
Display Color | 439, 804, 651, 110 | |||||||
Refresh Frequency (Hz) | ≥1000 | |||||||
Picture display method | Intellective control technology, test-itself technology, correct technology, Synchronization Control | |||||||
Input signal | DVI (S-VIDEO, CVBS, DP, HDMI, VGA, PAL/NTSC, etc. through a Video processor converting ) | |||||||
System operating | WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc. | |||||||
Front/Rear IP Level | IP43 | |||||||
Working temperature (ºC) | -20~+60 | |||||||
Stored temperature (ºC) | -30~+80 | |||||||
Operation humidity (RH) | 0-95% | |||||||
Display Lifetime (hours) | Ten years or more( natural environment) 100000 hours( ideal environment) | |||||||
Maintenance | Rear side | |||||||
Working Voltage | AC110 / AC220V±10% 47~63HZ | |||||||
Out of controlled dot | ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wavelength are both >10% depart to the normal one) |
(P6 Indoor High Resolution LED Display)
P6 Indoor LED Display Ultimate FAQ Guide
1. What is a P6 Indoor LED Display?
When purchasing or renting an LED screen, the term ‘pixel pitch’ is quite a common term that you might be familiar with already. The pixel pitch is a significant technical unit that is crucial for you to consider.
It refers to the distance between LED pixels. A P6 LED screen, for example, has a 6 mm dot pitch. A P6 module size of 23 pixels by 32 pixels has a pixel density of 27,777 pixels/m2.
A P6 Indoor LED display is an ideal solution for your large-size indoor video display applications. It is one of the best options available for indoor modular digital displays on the market.
The P6 LED screen includes a PCB board and LED chips that give off colored lights to allow you to display numerous content such as images, videos, text, and graphic effects on your LED display.
The best viewing distance for this LED screen, based on the 10x rule, is between 30 to 60 feet. This information is for a viewer with a 20/20 vision.
2. What LED Lighting Technology is Used in P6 Indoor LED Displays?
P6 LED video wall has adopted the SMD 3in1 technology. It is built using surface-mounted device panels (SMD) with red, green, and blue light-emitting diodes in one package (3in1). The LED components do not have to pass through the LED boards, but they are mounted directly on the PCB board. Also, this technology allows more LED electronics to be packed in a smaller space.
An LED display can deliver a good picture and image quality with surface-mounted technology, adequate brightness, and a wider viewing angle.
LED displays based on SMD technology are preferred for indoor applications because they produce enough brightness for the store, retail, commercial, and decorative purposes.
3. What are the Key Features of the P6 Indoor LED Display?
Here are some of the facts that you may expect from a P6 indoor LED display:
Multiple Installation Methods. Our P6 indoor LED display is available for various installation methods to meet your needs. It is suitable for hanging up on the ceiling, wall-mounted, or fixed installation on the stage.
Multiple Video Sources Inputs Compatibility. P6 LED video walls are compatible with all video and image input sources like HDMI, SDI signal, camera, laptop, computer, etc. It is equipped with a video processor LVP605S.
Fast Assembly and Dismantling. The P6 LED indoor display is modular and scalable to any size. It has a lock mechanism that offers a secured, tight, and easy fastening and unfastening of LED panels. For this reason, it is easy to move, transfer, and install. It is one of the must-have features for rental LED displays.
Seamless Screen Connection. Our direct-view P6 LED display is compact and has a slim and lightweight structure. LED panels are seamlessly connected, giving your audience an illusion that they are looking at a single LED screen. Seamless LED screens are advantageous in delivering quality and appealing visual effects.
Clear Images and Quality Pictures. The P6 indoor LED supports high-quality screen displays. It provides crisp and clear full-color images that are true-to-life looking. It is a great LED screen to make any content stand out among the crowd and catch viewers’ attention.
4. What are the Various Applications of P6 Indoor LED Displays?
One of the best advantages of the P6 indoor LED display is its several applications across various industries. You can use it to serve the following purposes:
- It can be an LED display screen for advertising in indoor places such as malls, airports, transport stations, supermarkets, etc. A P6 LED screen is a reliable digital tool to revamp or increase brand awareness by delivering exciting and engaging promotions and messages.
- It may function as an LED digital restaurant signage or display to attract more guests and diners. The P6 LED displays are capable of producing inviting audiovisual content that can lure and amaze people. But if you want to have a LED restaurant sign outside, choose a P6 outdoor LED screen with a higher IP rating.
- The P6 LED screen is also ideally used as an LED hotel sign or display board for hotels. It helps create a breathtaking display that will surely amaze and entertain any hotel guest.
- P6 LED video walls are applied in museums, planetariums, and indoor theme and entertainment parks to give the visitors a unique and unforgettable viewing experience. This visual experience contributes positively to the overall experience of the guests.
- The P6 LED screen is also one of the best preferred LED screens for the different stages. Whether it is for a church, social hall, or auditorium, the P6 LED wall is worth the price.
5. What are the Specifications of a P6 Indoor LED Display Module?
Below are some of the technical specifications or parameters of the P6 indoor LED screen.
P6 Indoor LED Display Parameters | |
Pixel Pitch | 6 (mm) |
LED Configuration (Encapsulation) | 3in1 SMD 3528 |
LED Pixel Density | 27,777 pixel/m2 |
LED Module Size | 192 (mm) x 192 (mm) |
Cabinet Size | 960 (mm) x 960 (mm) |
Refresh Rate | ≥ 1920 Hz |
Viewing Angle | 140 ° (horizontal); 140 ° (vertical) |
Gray Scale Grade | 16 bits |
IP level | IP43 |
Lifetime | 100,000 (ideal environment) |
Contact your LED screen supplier if you wish to know more about the parameters of P6 LED screens. The information provided may vary depending on every supplier.
6. What Much Would It Cost to Have a P6 Indoor LED Wall?
One thing that you need to note about LED wall displays is that they are modular and customizable. The price of the P6 indoor LED display is directly proportional to your LED needs.
A P6 video wall may range from $500 – $5000 depending on your LED screen size and other requirements. If you need a larger LED screen, it will require more LED screen panels. And the opposite, if you will only need a small LED sign.
It is the main reason why LED display suppliers and manufacturers do not usually include prices on their websites. LED solution providers must know your requirements first before they can send you a price quote.
You can message your video wall solution provider now to request to know more about their product and services pricing. They will send you a detailed quote once they learn about what you need.
7. What Can I Expect from YUCHIP’s P6 Indoor LED Display?
YUCHIP is known in the global market as a reliable LED wall and signs solutions provider. Since its foundation in 2004, we have produced quality, personalized LED solutions to serve our clients here and abroad.
You can expect high-quality products coupled with top-notch technology from us. We make sure that every LED screen we produce delivers excellent performance and superb display quality.
Our LED products are export-quality, ISO certified, and past international standards. We offer a 3 to 5 years warranty for our products to guarantee that you will make the most of your LED screen investment.
We promise to guide you with your LED project from start to end. We offer after-sales services and responsive customer care and support to ensure that you will be satisfied with your purchase.
If you want us to be part of your LED display journey, please send us a message, and we will be more than happy to partner with you.
If you are in search of high-quality P6 indoor LED displays and accessories, message us today. Otherwise, you can provide us with the information on your desired LED screen, and we will offer you a customized solution. We have got it all for you.
8. P6 LED Screen Conclusion
For every LED display you need for your store, advertising screen, or future event, there is a suitable LED screen for that.
Remember that the pixel pitch of an LED screen is a factor that affects the viewing experience of the audience. Nonetheless, whether you choose P4, P6, or P8, they will all deliver excellent performance, provided they are intelligently installed.
A P6 LED screen display is one of the most sought-after solutions for indoor use. Whether your goal is to deliver eye-catching marketing content or give your audience a captivating visual experience, you can rely on a P6 LED display.
